Printers Guide

Configure network printers, manage print jobs, and print labels and documents from DataMagik scripts and automations.

Table of Contents

1. Overview
2. Printer Types
3. Adding a Printer
4. IPP Printer Discovery
5. Print Jobs
6. ZPL Label Printing
7. Printing from Scripts
8. Job History
9. Best Practices

1. Overview

The printing system enables you to send print jobs to network-connected printers through your on-premise connectors. It supports both standard document printers (via IPP) and thermal label printers (via ZPL).

Key Features:

• Multiple Printer Types — IPP network printers and Zebra thermal label printers
• Multiple Formats — ZPL, PDF, and HTML print jobs
• Automatic Failover — Jobs route to alternate connectors if one fails
• Priority Queuing — Higher priority jobs are processed first
• Retry Logic — Failed jobs retry with exponential backoff
• Full Audit Trail — Complete job history with timing and status

2. Printer Types

Zebra / ZPL Printers

Thermal label printers that accept ZPL (Zebra Programming Language) commands.

• Protocol: Raw socket (direct TCP)
• Use Cases: Shipping labels, part labels, barcodes, asset tags
• Settings: Darkness, print speed, media type, tear-off offset, print width

Generic IPP Printers

Network printers supporting the Internet Printing Protocol.

• Protocol: IPP
• Use Cases: Documents, reports, packing slips
• Formats: PDF, HTML
• Authentication: Optional username/password and TLS

3. Adding a Printer

Step 1: Navigate to Printers

Go to Connectors → Printers in the main menu.

Step 2: Click "Add Printer"

Click the Add Printer button.

Step 3: Configure Printer Settings

For IPP Printers

For Zebra Printers

4. IPP Printer Discovery

Automatically discover available print endpoints on network printers using IPP probing.

How to Probe

1. Click Probe on a printer or enter an IP address
2. The system sends a discovery request through your site's connector
3. Discovered endpoints are returned with printer details

Discovered Information

• Available print endpoints (e.g., /ipp/print)
• Printer name and make/model
• Supported formats (PDF, etc.)
• Color support
• Current state (idle, processing, stopped)

Requirement: At least one online connector must be active at the target site for probing to work.

5. Print Jobs

Job Lifecycle

Triggering a Print Job

Print jobs can be triggered from:

• Scripts — Using the manufacturing object (see Section 7)
• Automations — As an action in DataMagik Automate
• API — Direct API call with printer ID and print data

Supported Input Formats

Priority & Failover

• Jobs are processed by priority (higher number = higher priority)
• If a connector fails, the job is automatically routed to another connector at the same site
• Failed jobs retry with exponential backoff up to the maximum attempt count
• Stale locks (processing for over 5 minutes) are automatically released

Cancelling a Job

Jobs in pending or failed status can be cancelled. Jobs that are actively processing or already completed cannot be cancelled.

6. ZPL Label Printing

Send ZPL commands directly to Zebra printers for high-speed label printing.

Direct ZPL

^XA
^FO50,50^A0N,50,50^FDHello World^FS
^FO50,120^BY3^BCN,100,Y,N,N^FD12345678^FS
^XZ

Template-Based Printing

Use ZPL templates with data placeholders for dynamic label content. Placeholders like {partNumber} are replaced with actual data at print time.

ZPL Preview

Preview ZPL output before printing using the ZPL preview tool. This renders the ZPL as an image so you can verify the label layout.

7. Printing from Scripts

The Script Engine provides a manufacturing object for printer operations:

function main(context) {
  // List available printers
  const printers = manufacturing.getPrinters();

  // Get a specific printer
  const printer = manufacturing.getPrinter("Line1-Zebra");

  // Send raw ZPL
  manufacturing.printLabel("Line1-Zebra", "^XA^FO50,50^A0N,50,50^FDHello^FS^XZ");

  // Print using a template with data
  manufacturing.printFromTemplate("Shipping-Printer", "ShippingLabel", {
    orderNumber: context.order_id,
    customerName: context.customer
  });

  // Batch print multiple labels
  manufacturing.printBatch("Line1-Zebra", "PartLabel",
    context.parts.map(p => ({
      partNumber: p.number,
      serialNumber: p.serial
    }))
  );

  return { success: true };
}

8. Job History

All completed and failed print jobs are archived for audit and troubleshooting.

Viewing Job History

Navigate to Connectors → Print Jobs to view:

• Job status (completed, failed, cancelled)
• Duration (how long the print took)
• Attempt count (how many retries were needed)
• Error messages (for failed jobs)
• Who triggered the job
• Source (API, UI, automation, or script)

Active Jobs

View currently pending and processing jobs per printer to monitor the queue in real time.

9. Best Practices

Printer Setup

• Use descriptive names — Include location and type (e.g., "Dock A - Zebra 4x6")
• Assign to correct site — Ensures jobs route through the right connector
• Use IPP probe — Auto-discover endpoints rather than guessing paths
• Test after setup — Send a test print to verify connectivity

ZPL Labels

• Use templates — Reusable templates with data placeholders are more maintainable
• Preview first — Use ZPL preview before sending to the printer
• Batch for volume — Use manufacturing.printBatch() for multiple labels

Reliability

• Multiple connectors per site — Enables automatic failover
• Monitor job history — Check for recurring failures
• Use priority — Set higher priority for time-sensitive print jobs
